Command Parking Flush Mount Sensor Front Kit With Silver Sensors 40KHz

Command Parking Systems™ 40 years of extensive experience in the automotive aftermarket including provision of

Some of the best electronic products available

Features and Benefits:

Assistance detecting obstacles whilst reversing your vehicle.
Audible alarm and optional visual display with many models.
Increases safety levels when children are playing near the vehicle.
May prevent collisions with unseen objects behind your vehicle.
Assists to safely park your vehicle with front and rear sensors (front sensors on selected models only).
Added vehicle resale value.
Command Parking Systems™ are a valuable addition to your vehicle.

High quality, reliable and valuable electronic vehicle accessories.

Command Parking Systems™ are manufactured in ISO approved manufacturing facilities and are covered by Command Auto Group's trusted national warranty service.

12 month warranty is applied for installations done in a DIY installation.

24month warranty is applied for units that have been installed by a professional approved installer. In a vehicle of any age.

Warranty is extended up to 3 years when installed by professional installers in new vehicles during pre-delivery.

Command Auto Group and their range of Command Parking Systems™ are continuing the leadership in innovation with new innovative products for the more unique vehicle applications.

Note: eBay's compatibility table is not accurate in some cases. Please refer to the following information we have provided for you.

Brand : Command

Contents :Parking Sensor Front Kit With Silver Sensors

FRONT SENSOR SYSTEM ¨C CMD05-4F

The 91CMD05-4F Command Front Parking Sensor System aids in the detection ofobstructions in front of your vehicle.

As this kit is designed for front fitment,power is not taken from the reverse lamp power feed and rather taken from ignition with both brake pedal activation as well as offering a manual activation/deactivation button for added safety.

After applying the brake pedal the system will activate and remain active for 15 seconds. If an obstruction is detected during this period the timer restarts for another 15 second cycle. If an obstruction is not detected the system reverts to stand-by mode. All 4 sensors must be fitted to vehicle.

Obstruction Warning Guide:

0.7m ¨C Slow warning beep and red indicator light as distance decreases.

0.3m ¨C Rapid warning beep and red indicator light as distance decreases.

Sensitivity Adjustment:

Adjustments that can be made to reduce sensor sensitivity levels.

The final (rapid) warning stage can be set at 0.3 or 0.5 meters via a switch on the Digital Control Module.

The volume of the warning signal and detection distance can also be adjusted via a switch on the Digital Control Module.

Sensor Specifications

Sensor fitment: Flush mount
Sensor colour: Black ¨C paintable
Sensor size: 25mm outer,21mm inner (21mm deep)
Warning type: Audible buzzer with flashing lights ¨C brake light activation with 15sec shutdown delay
Detecting range: 0.2-0.7m adjustable to 0.3-0.5m
Sensor adjustment: Yes ¨C DIP switch
Volume adjustment: Yes ¨C adjustable high/low
Ingress protection: Sensor IP67,module none
Connector type: Screw type to small 2 pin
Frequency: 40KHz
Power supply: 9-16v
Lead length: 4.8m (sensor to module)
Pack Includes: 4 x black flush mount sensors,1 x CMDO5 front sensor module,1 x buzzer,power harness,21mm hole saw,3M sticky backed Velcro,cable ties,manual activation switch.
